CES Ultra Technical Specifications

The Most Commonly Used Cranial Electrotherapy Stimulation in the U.S. Features:

  • Frequency: 100 Hz (100 pulses per second)
  • Power source: 9 V alkaline battery
  • Wave shape: Modified square wave
  • Amplitude: Adjustable from 0-1.5 mA (milliamps)
  • Pulse duration: 2 milliseconds (20% duty cycle)
  • Current intensity: up to 1 mA (milliamp)

Physical Specifications:

  • Base unit weight: 4.5 oz
  • Base unit dimensions: 4.25 in x 2.5 in x 1.0 in
  • Carrying case dimensions: 8.25 in x 7.0 in x 1.75 in
  • Lead wire length: 3.5 ft
cesultra kit

Using The CES Ultra

CES Ultra users

CES therapy is simple and easy. The CES Ultra is the most user-friendly CES device on the market. Enjoy the gentle massage-like action and pleasant tingling sensation. You have one-touch control of the unit at all times.

  • Simple to operate
  • Automatic shut-off
  • Push-button timer: 30, 45 and continuous
  • Single-control setting
  • Comfortable ear-clips or pre-gelled electrodes
  • Rugged construction
  • Fitted carrying case
  • Compact portability for hand-held use or carrying in a pocket
  • Low-battery indicator
  • Uses a standard 9-volt battery

Instructional Video

CES Presentation

CES Ultra Research presentation
